Комнатный контроллер Contouch, с шинным соединителем, титаново-белый

SiemensКомнатный контроллер Contouch, с шинным соединителем, титаново-белый.

Multifunctional display/operating device for KNX, with 320 x 240 pixel, 2.8" LCD color display
For the display and operation of at least 18 configurable room operator functions:
Switching On/Off/Over and Pushbutton function (bell function)
Shutter/blind/roller control
Value transmission: 1 byte in %, 1 byte integer without prefix, 1 byte integer with prefix, 2 byte integer without prefix, 2 byte integer with prefix
Positively driven operation
Scene control: Store and call up scene 8 bit, store and call up scene 1 bit
Text display and warning and alarm indications
Operation using touch screen and/or by turning/pushing rotary/push button
RGB LED as orientation light or for signaling alarm indications
Buzzer for acoustic alarm indication or as feedback when operating touch screen
Integrated room temperature sensors
Analysis and weighting of an external inside temperature sensor
Room temperature control can be set as a two-point control and/or continuous-action control for heating only, for cooling only, or for heating and cooling mode
Operating modes that can be switched via KNX: comfort mode, pre-comfort mode, energy-saving mode and frost or heat protection mode
Local displaying of active operating modes or automatic or manual modes
Local displaying of heating/cooling valve open, dew point alarm and open window
Local switchover between automatic or manual mode, and between comfort, pre-comfort, energy-saving and protection modes
Local, time-adjustable extension of comfort mode
The room temperature setpoint value for comfort mode can be set via a rotary button on the room controller
Basic room temperature setpoint value for comfort mode which can be set via the KNX
Outdoor temperature-based tracking of temperature setpoint value in cooling mode
Adjustable dead zone between the heating setpoint and the cooling setpoint for comfort mode
Two-level heating or cooling
Output of the control variable(s) either as an on/off switch command or as a positioning command in the range of 0...100%
Local displaying of manually set fan speed step or automatic speed input
Fan speed step can be set via the rotary button or entered automatically by the controller
Weekly scheduling program for controller operating modes and for 18 room operator functions
At least 16 time switching points per function per weekday
Display of date and time
Selection of at least 4 different design templates as operator and display interface
Local activation of a cleaning function to lock the touch screen and the rotary/push button
Slot for a micro SD card for transferring firmware and configuration data
incl. bus coupling unit (included in delivery)
Bus connection via bus terminal
Connection of the separate 24 V DC boost voltage, power consumption approx. 50 mA
Flush-mounting device for mounting in a д 60 mm installation box, with screw fixing
Размеры (Ш х В х Г) 86 x 116 x 30 ммВсе технические характеристики
