Комнатный контроллер температуры UP 237K/31, алюминиевый металлик

Контроллер температуры, алюминиевый металлик.
Integrated room temperature sensors
Control can be set as a two-point control and/or continuous-action control (P or PI algorithm), for heating only, for cooling only, or for heating and cooling mode
Operating modes that can be switched via KNX: comfort mode, pre-comfort mode, energy-saving mode and frost or heat protection mode
Presence pushbutton to locally switch between comfort and pre-comfort mode or comfort and energy-saving mode and to extend comfort mode after operating energy-saving or protection mode
Pushbutton for switching over between manual and automatic mode
The room temperature setpoint value for comfort mode can be set via an interchangeable rotary button (+/-) on the controller and via the KNX
Basic setpoint of the room temperature for comfort mode which can be set via the KNX
Setpoint value for comfort mode in °C which can be set via an interchangeable rotary button on the controller
Adjustable dead zone between the heating setpoint and the cooling setpoint for comfort mode
Two-level heating or cooling
Output of the control variable(s) either as an on/off switch command or as a positioning command in the range of 0...100 %
5 LEDs to display manual mode and the current operating modes
4 LEDs to display heating/cooling valve open, dew point alarm and open window
For plugging onto a bus transceiver module (BTM) or a flush-mounting actuator with bus transceiver module (BTM)
Размеры (Ш х В х Г) 55 x 55 x 16 мм
